ESP32-CAM motion detection streaming

In the post about motion detection (you can find a link at the bottom of this page), we inspected the results of motion detection in the Serial Monitor. It would be great if we could visually inspect them, instead. This is indeed possible using a built-in web server that serves both the camera stream and the motion results at the same time.

For motion detection configurations available, refer to the aforementioned post. The only parameter you can configure for the server is the ratio threshold: above this value (from 0 to 1), you will see a message on the debugging web page which highlights that motion has been detected.

Here's the sketch.

Replace SSID and PASSWORD with your WiFi credentials

/**
 * Motion detection example, debug server.
 *
 * Motion detection requires the JPEGDEC library
 * (https://github.com/bitbank2/JPEGDEC)
 */
#include <JPEGDEC.h>
#include <eloquent_esp32cam3.h>

using eloquent::camera::Camera;
using eloquent::camera::motion::MjpegServer;
using eloquent::camera::helpers::net::wifiConnect;
using eloquent::camera::helpers::net::setHostname;

Camera camera;
MjpegServer server(camera);


void setup() {
    Serial.begin(115200);
    Serial.println("Motion detection: debug server");

    // see "GetStarted.ino" for more comments
    camera.hardware.brownout.disable();
    camera.hardware.clock.fast();
    camera.hardware.pinout.ask();
    camera.frame.resolution.vga();
    camera.frame.quality.high();

    // see "MotionDetectionSimple.ino" for more comments
    server.motion.stride(16);
    server.motion.differBy(30);
    server.motion.smoothBy(0.2);
    server.motion.trainFor(10);

    // display message on webpage
    // when motion ratio is above this value
    server.triggerAbove(0.3);

    // connect to Wi-Fi
    // make webserver available at http://esp32cam.local
    wifiConnect("SSID", "PASSWORD");
    setHostname("esp32cam");

    // init camera
    camera.begin();
    camera.raise();

    // init server
    server.begin();
    server.raise();

    // print server instructions
    Serial.println(server.help());
}


void loop() {
    // web server runs in background
    delay(1000);
}

After the sketch is flashed, open the Serial Monitor. You will find a message similar to the following line:

Motion server available at http://192.168.X.Y

The exact IP address will vary depending on your network. If your router supports it (most do), you should also be able to visit

http://esp32cam.local

ESP32-CAM motion detection streaming
